JS-16A Automatic Auger Type Powder Filling & Packaging Machine
Overview
Chung Shan Machinery Works Co., LTD. is a professional manufactures of Packaging Machine, Powder Filling Machine, Granule Packaging Machine, Filling And Packaging Machine, Powder/Granule Packaging Machine and Automatic Auger Type Powder Filling & Packaging Machine.
Application
- Applicable packing products : Various powder, such as: seasoning powder, milk powder, flour powder, rice powder …etc.
- Applicable packing materials : Double layer heat seal suitable laminated film, such as: PET+LLDPE, PET+MPET+CPP, PET+PE+AL+LLDPE, Nylon+LLDPE…etc.
Features
- PLC Control + Servo Motor for ease operation.
- Touch Panel for easy usage to set up: bag length, filling weight, speed, sealing temp, eye mark, counter, QTY warning, memory record…etc.
- Auger screw is one-piece formed and which is manufactured of stainless steel 304, comes with food sanitary standards.
- Suitable for light density, hard flowing related powder.
- Filling Weight adjustable through panel directly.
- Pneumatic sealing type for nice sealing packaging performance.
- Enable to set up required sealing & cutting time.
- Film tension control for stable film filling & pulling.
- Sealing and cutting operations are air cylinder activated for fast, highly efficient operations.
- Multiple memory programs to record/read different packaging data.
- Auto eye mark tracing in a short time.
- Auto warning display for quick trouble shooting.
- PID function temp. controller for each sealing part with stable sealing performance.
Optional Device
- Date coder, product input / output conveyor, nitrogen air connector, quantity warning,…etc., and other required device upon request.
-
Sealing Type
Specification
| JS-16A PLC Control + Servo Type + Pneumatic Sealing |
| Sealing Style |
3 sides, 4 side or pillow type packaging(one option) |
| Motor |
PLC Control + Servo Motor |
| Power |
220V, 50 or 60 Hz, 3 phase(upon request) |
| Film Width |
60-160 or 80-220mm |
| Bag Length |
80-170mm |
| Filling Weight |
10-30g / 30-50g / 50-100g(varies with product density) |
| Packaging Speed |
About 20-70 bags/min |
| Machine Dimension |
174 x 132 x 185cm(L x W x H) |
| NET Weight |
560kg |
Other packaging sizes available upon request.
Filling weight& Packaging speed will be differ from product density, weight & film.
6kg/cm2 compressed air with dry air filtering system self-prepared is required. |
Video
-
