EZ-280BF Vertical Multilane Power Packaging Machine
Overview
The EZ-280BF powder filling and packaging machine utilizes servo screw,. measuring cup, disc feeder, and other methods for measurement. It automatically performs bag-making, filling, sealing, printing, easy-tear notch cutting, and finished product conveying.
Application
- It is suitable for various food powder and granule products such as pharmaceuticals, probiotics, collagen powder, nutritional supplements, and instant granules.
Features
- Equipped with a film detection mechanism, it provides early notification to operators for film replacement, avoiding wastage of film material.
- The machine utilizes servo film pulling and precise photoelectric detection system to ensure accurate and consistent product dimensions.
- Optional features include a dust removal system and water cooling system for high dust and high sugar content powder products.
Specification
| Model |
EZ-280BF (Type 280, Type 560, Type 840)
|
|
Packaging material
|
OPP/CPP、OPP/CE、MST/PE、PET/PE
|
|
Sealing method
|
Back seal、Round cut、Zig Zag、Die-cut
|
| Film width |
440-650mm |
| Bag width |
20-65 mm |
| Bag length |
50-150 mm |
|
1 Lane Packing speed
|
20-30 bags/min/lane
|
|
Air requests
|
8kg/cm2 600L/min
|
|
Power supply
|
AC 220V, 1 ph , 60 HZ, 3.5 KW
|
| Weight |
400 kgs |
|
Machine Dimension
|
1440 (L) x 1100 (W) x 3500 (H) mm
|
|
Filling type
|
Long auger、Short auger、Short with cup
|
