Multi-head Scale Packing Machine CY-602S

Overview
Yueh Chyun Machinery Co.,LTD is specialized in Packing Machine and Food Packing Machine.
Application
- The multi-head weighing system has high accuracy and with the two servo driven packing machine, the whole machine system has high efficiency and high stability. Also the multi-head packing machine is in wide applications for varieties of products:
  Snacks:cookies、potato chips、chocolate、mixed nuts.
  Frozen foods:frozen vegetables and fruits, frozen meat and seafood.
  Seafood and meats:shrimps,calms, scallops.
  Dairy products:shredded cheese, cheese cubes.
  Fresh produce:cherry tomatoes, baby carrot, chopped vegetables, salad.
  Fresh fruits:all type of berries, diced fruits.
Features
Packing Machine
- 7"Color Touch Panel- simple operating and user friendly.
- PLC control-programmable logic control.
- Servo motor film pulling - easy setting for the bag length and accurate positioning.
- Seal jaws servo motor controlled-reduced air usage and enhance sealing sensitivity.
- PID temperature control on each heater to provide quality sealing -reducing the waste of the film.
Weighing System
- All stainless steel SUS304 construction
- Windows operation system
- 17" color touch screen
- PC panel with wireless online support
- 99 sets of programmed memories

Specification

MODEL	CY-602-S
Bag Type	Pillow Bag
Bag Size	Standard - W:100-210L:100-280mm / Large - W:200-300L:200-400mm
Film Size	Standard - 230-450mm / Large - 430-630mm
Dosing Method	Multi-head computerized scale.
Capacity	15~40 bags/min.(subject to film quality, filling volume and product conditions.)
Voltage	220V/60Hz
Machine Weight	750kg
▲ Above specifications for standard machine only. ▲ Actual machine appearance may vary.
