CMS-Q1 PET Fully Electric Stretch Blow Molding Machine

PET Fully Electric Stretch Blow Molding Machine, CMS-Q1
  • Overview

    CMS-Q1
    CMS-Q1 is for 5 Gallon Water Bottle.It is a new development machine of 5 gallon PET water tank for medium scale factories. Ideally suitable for for applications where stringent quality requirements have to be met. Inaddition, weare pride to show our clients the technical know-how for processing PET preforms on our automatic machine to produce 5 gallon PET water tank which is cost effective alternative to the traditional 5 gallon PC water tank.

  • Application

    • Water & Beverage Packaing
  • Features

    • Preform In-feed and Unscrambler:Orientation and delivery of preforms is in an orderly fashion to the machine. Accurate position control of preform is achieved by pneumatic system.
    • Mould Open-Close System:Using servo motor control to optimize the movement such as more accurate positioning, better stabilization, low noise and more efficiency
    • Mandrel Claw:Use pneumatic system transform and servo motor movement to control position of preform before blowing.
    • Stretch Blow System:Servo motor drive enables accurate position. Blowing cinditions is more stable and high efticiency.
  • Specification

    Model CMSQ1
    Container Max. neck diameter mm Ø55
    Max. production capacity pcs/hr 300~400
    Max. body diameter mm 300
    Max. container height mm 500
    Max. bottle capacity ml 20000
    No. of cavity no. 1
    Heating oven No. of oven no. 3
    NO. of infrared heaters ineach no. 16
    Heating load (max.) kw 96
    Air pressure Low pressure kg/cm2 7
    High pressure kg/cm2 35
    Cooling water Cooling capacity kcal/h 18000
    Water consumption l/min 80
    Water temperature °C 10~12
    Pressure bar 5
    Total consumption power kw 87.8
    Machine dimension m 4.0x2.2x3.5
    * All Specifications and designs are subject to change without notice.
